76 76 V V 1.01.0


Service ManualService Manual
Operating Lights marLEDOperating Lights marLED
®®
E9 / E9i / E15E9 / E9i / E15
VV 1 01 0 7777
Life hazard or danger of Life hazard or danger of severe injuries!severe injuries!
If the torques indicated above cannot be reached for one or more heavy-duty anchors,If the torques indicated above cannot be reached for one or more heavy-duty anchors,
reinstall the ceiling anchor plate by taking suitable measures (e.g. enlarge mounting holes orreinstall the ceiling anchor plate by taking suitable measures (e.g. enlarge mounting holes or
move plate, drilling new move plate, drilling new holes for plate installation)!holes for plate installation)!
••

√√ (plus (plus torque)torque)
Intermediate ceiling assembly torqueIntermediate ceiling assembly torque
1 1 Ceiling Ceiling anchor anchor plateplate
2 2 M16 M16 nutnut
3 3 Intermediate Intermediate plateplate
Fig. Fig. 10-2 10-2 Checking Checking the the torques torques on on the the intermediate intermediate ceiling ceiling constructionconstruction
••
 Check all M16 fixing nuts of the ceiling anchor plate and the intermediate plate (ifCheck all M16 fixing nuts of the ceiling anchor plate and the intermediate plate (if
applicable) for proper tightening, using a torque of 65 Nm.applicable) for proper tightening, using a torque of 65 Nm.
••

√√
Torque checks on Torque checks on intermediate ceiling assembly!intermediate ceiling assembly!

If the torques of the heavy-duty anchors and the intermediate ceiling assembly have beenIf the torques of the heavy-duty anchors and the intermediate ceiling assembly have been
documented in the Handover Report, the technician may check them again if considereddocumented in the Handover Report, the technician may check them again if considered
necessary.necessary.

WARNINGWARNING
NOTICENOTICE
