Section 11
Parts List
20425652
5-2005/Rev 0
11-8
Table 11-2
Intensifier Assembly
80079999
Item
Part
Number
Description
Quantity
Item
Part
Number
Description
Quantity
1 05144647 HP Cylinder Body, 1.125 x 8 2 14 05034764 Hydraulic Cylinder, 6.22 x 4.03 x 14.96 1
2 05119151 Ceramic Plunger, 0.875 2 15 10075000 O-Ring, 3-3/4 x 4 x 1/8 2
3 80072349 Sealing Head Assembly 2 16 05034855 Backup Ring, 3-3/4 x 4 2
4 05034772 Hydraulic Cylinder Head 2 17 05141106 Socket Head Screw, M14 x 60 16
5 05149703 HP Seal Assembly, 0.875 2 18 05127584 Proximity Switch, 20-250V AC/DC 2
6 05144696 Spacer, Sealing Head 2 19 10183572 Socket Head Screw, M6 x 1.00 x 22 MM 4
7 80073646 HP Cylinder Nut, HSEC 2 20 05132253 Piston Assembly, 4.03 Diameter 1
8 05130091 Hydraulic Cartridge Seal Assembly 2 21 10074409 O-Ring, 1 x 1-1/4 x 1/8 2
9 05007786 Bushing Retainer Flange 2 22 05144183 Spacer, Proximity Switch 2
10 20418805 Liner, HP Cylinder 2
11 10074920 O-Ring, 1-3/4 x 1-15/16 x 3/32 4
12 80070352 Jackbolt, 7/16-20 x 2.31, 3/8 Hex Head 12
13 05034798 Retaining Ring 2
