Section 10
Specifications
20425644
5-2005/Rev 0
10-2
Equipment Dimensions and Weights
Total Length Base Length Width Height Weight
53.50” (1,359 mm) 44.00” (1,117 mm) 32.39” (823 mm) 37.00” (940 mm) 1,750 lbs (794 kg)
Redundant Model
39.07” (992 mm) 28.25” (718 mm) 2,030 lbs (921 kg)
Service Connections
Cutting Water Out 9/16” HP Connection
Plant Air In (optional) 1/4” NPT Connection
Cooling Water In 1/2” NPT Connection
Cooling Water Out 1/2” NPT Connection
Cutting Water In 1/2” NPT Connection
Drain (optional) 1/2” NPT Connection
10.3 Water Specifications
Cutting Water Supply (Low Pressure Water System)
Minimum inlet flow 2.5 gpm (9.5 L/min)
Minimum inlet water pressure 35 psi (2.4 bar) flowing, with optional booster pump
60 psi (4 bar) flowing, without booster pump
Maximum inlet water pressure 100 psi (6.9 bar)
Maximum booster outlet water pressure 120 psi (8.3 bar)
Booster pump factory set inlet pressure 58 psi (4 bar)
Booster pump factory set outlet pressure 120 psi (8.3 bar)
Optimum inlet water temperature
65° F (18° C)
Maximum inlet water temperature
85° F (29° C)
Booster pump overheat, recommended
128° F (53° C), with optional booster pump
To Next Page
