Section 10
Specifications
20425644
5-2005/Rev 0
10-7
High Pressure Water System
Plunger diameter 0.875” (22 mm)
Piston diameter 4.03” (102.4 mm)
Intensification ratio 20:1
Maximum flow rate
60,000 psi (4,137 bar) 0.52 gpm (1.97 L/min)
Minimum outlet pressure 5,000 psi (500 bar)
Maximum outlet pressure 60,000 psi (4,137 bar)
Pneumatic Control Valve
Maximum water pressure 60,000 psi (4,137 bar)
Minimum air pressure 85 psi (5.9 bar)
Maximum air pressure 100 psi (6.9 bar)
Maximum air flow rate 1.0 cfm (0.028) m
3
/min
Orifice Capacity
The following tables provide horsepower requirements for some of the more popular orifices.
Table 10-4
Single Orifice Diameter
Motor
Horsepower
Rating
Model
HP Kw
Maximum
Operating
Pressure
Maximum Single
Orifice Diameter
(at full pressure)
S30 30 22 60,000 psi (4,137 bar) 0.010 inch (0.254 mm)
