SECTION 1
INTRODUCTION
1.1 Overview
The Streamline S30, specifically designed for integration into a waterjet cutting system, combines
all the unique capabilities and advantages of waterjet cutting with the reliability, ease of operation
and service support that have made KMT Waterjet Systems a leader in waterjet technology.
The S30 does not include a control panel or enclosure and will not run as a stand-alone unit. An
electrical interface allows the system builder to supply all power, control and logic interface to
the intensifier from the motion control panel. The entire cutting system can be operated and
controlled from one location.
Table 1-1
Streamline S 30
Motor
Horsepower
Rating
HP Kw
Maximum
Operating
Pressure
Maximum
Flow Rate
(at full pressure)
Maximum Single
Orifice Diameter
(at full pressure)
30 22 60,000 psi (4,137 bar) 0.52 gpm (2.0 L/min) 0.010 inch (0.254 mm)
The S30 is available with a single or redundant intensifier. The redundant unit allows operation
to continue if a problem is detected on the active intensifier. Operation can be switched to the
secondary intensifier until the next convenient shutdown, when service can be performed on the
primary intensifier.
1.2 Performance Features and Options
The S30 is designed with the same convenience and ease of access for maintenance and service
you have come to expect from KMT Waterjet. The hydraulic cylinder head simply bolts to the
hydraulic cylinder; each high pressure assembly can be removed and serviced independently, and
the hydraulic seal cartridge can be quickly replaced as a single unit.
The robust performance and standard features are the result of aggressive development and
decades of experience.
• Continuous operation at 60,000 psi (4,137 bar).
• The innovative hard seal end cap provides a metal-to-metal seal against the sealing head,
totally, eliminating the potential for leaks.
• While dramatically increasing seal life, the unique design of the patented HyperLife
TM
seal conforms to the cylinder bore as it expands under pressure, creating an absolute seal.
