Section 11
Parts List
20425652
5-2005/Rev 0
11-14
Table 11-6
High Pressure Piping
05142500
Item
Part
Number
Description
Quantity
1 05127519 HP Tube, Bent, 0.38 x 0.125 1
2 05127501 HP Tube, Bent, 0.38 x 0.125 1
3 10078590 HP Tee, 0.38 2
4 05142187 Manifold Assembly 1
5 05141882 HP Tube, Bent, 0.38 x 0.125, Cone/Thread 1
6 10078129 HP Gland, 0.38 2
7 10078715 HP Collar, 0.38 2
8 80079999 Intensifier Assembly 1
9 10079523 HP Plug, 0.38, 17-4 1
10 10083897 Ferrule, 0.25 Hose 8
11 05028030 HP Tube, 0.38 x 0.125 x 6.75, Cone/Thread 1
12 95413696 Lock Washer, 0.50 x 0.125 5
13 10186153 Conduit, Extra Flexible, 0.38 ID 70.0"
14 95738514 Hex Head Screw, 1/2-13 x 1 5
