Section 5
Recirculation System
20425595
5-2005/Rev 0
5-3
Do not attempt to fill the reservoir from the air breather. The oil will not be
filtered and will not conform to the cleanliness requirements of the system.
Figure 5-2: Hydraulic Oil Reservoir, Single Intensifier
Figure 5-3: Hydraulic Oil Reservoir, Redundant Intensifier
1. Turn the machine off and observe the appropriate Lockout/Tagout procedures.
