Page #144 background imageLoading...
Page #144 background image
SECTION 12
PARTS LISTS
page 12-10
80079163
Figure 12-4 HYDRAULIC PISTON ASSEMBLY 05132253
ITEM No. QTY PART No. DESCRIPTION
1 1 05132261 Body, Hydraulic Piston
2 12 05074380 Pin, Clevis
3 2 05049887 Screw, Set, Socket, with Through Hole
4 2 10148757 Valve, Check, Cartridge, with O-ring
5 -- 49877509 Adhesive, Thread Locker
6 2 05088364 Ring, Snap, Flat Wire
7 2 05049994 Ring, Backup
8 2 05087713 O-ring
9 1 05117965 Seal Assembly, Hydraulic Piston
10 2 05117940 Bearing, Hydraulic Piston
