SECTION 4
MAINTENANCE
Page 4-6
49831902
4.3 Service Log Data
Maintaining a book of Service Log Sheets such as shown in the following pages
can be a useful method for ordering spare parts, and for tracking maintenance
trends on the SL-IV high pressure intensifier pump. Each part replaced should
be noted with the following information: date, person, operating hours, and
parts replaced. The Service Log data sheet and part identification illustrations
provide a simple means of noting the part(s) service/ replaced. Identify the
part(s) serviced or replaced in the accompanying figure and parts list then mark
the box under the number corresponding to that part’s balloon number in the
figure. If there are special conditions that might relate to that part’s service
history, write comments to the side or add to the bottom or separate sheets of
paper. Note that if there are two intensifiers on the pump (redundant option)
then indicate which intensifier (I or II) in the column labeled “Intensifier”. Note
that intensifier I is located to the front when standing such that the control
panel is to one's left and the plumbing connections are to the right rear of the
pump. Also note which HP cylinder is being serviced: Cylinder A is closest to
the electrical control panel.
Service life of certain HP components can be analyzed using the Service Log
sheets. Subtracting operating hours between part changes provides service life
information. If questions arise concerning service history, then the Service Log
sheets can be faxed to the KMT Waterjet service office. Having a mutually –
understood form of recording service history (that is, the Service Log sheets) is
an advantage when drawing the attention of KMT Waterjet service personnel to
the particular service problem.
Note
: SLIV 100D intensifiers with flanged ends do not have item (6) sealing
head HP seal.
