1.2 Functional Description
The SL-IV Waterjet Pump meets the automotive and industrial markets needs of
low to high volume production of water jet pumps. The maximum HP water
pressure is limited by a hydraulic relief valve that is factory certified and sealed.
No HP rupture disk is required.
HP water is produced by an intensifier consisting of two HP water cylinders
mounted to a hydraulic cylinder. Ceramic plungers (2 per intensifier) attach to
the hydraulic piston and extend into each HP cylinder. With two intensifiers
mounted on one SL-IV frame, both may operate simultaneously (dual) or one
may serve as stand-by for the other (redundant). Piston travel is sensed
electronically by proximity switches which control hydraulic flow to/from the
double-acting hydraulic piston/cylinder.
Refer to Table 1-2 for HP water performance limits for various power levels of
SL-IV waterjet pumps.
TABLE 1-2 HP WATER PERFORMANCE-
SL-IV WATERJET INTENSIFIER PUMPS
55,000 psi 60,000 psi
Horsepower
Orifice Size
(inches)
Flow Rate
(gpm)
Orifice Size
(inches)
Flow Rate
(gpm)
30 0.011 0.60 0.010 0.52
50 0.014 0.98 0.013 0.88
60 0.015 1.12 0.014 1.02
75 0.017 1.44 0.016 1.33
100 0.020 2.00 0.019 1.88
The recirculation hydraulic loop for cooling and filtering oil runs continuously
whenever the motor is running.
1.2.1 Functional Features
Following is a list of SL-IV Waterjet Pump features:
• 4,136 bar (60,000 psi) operating pressure
• Electronic reversing
• 24 vdc safety control
• Standard high pressure water leak detection
• Standard dual pressure control facilitates hole piercing and kiss cut
applications
• Exclusive long slow stroke
• Cartridge type hydraulic seal
• Low pressure water booster pump and filtration
• Reduced cooling water requirements
• Choice of English, German, Spanish, Swedish and Italian readouts as
standard
• Meets CE requirements
