KMT STREAMLINE SL-IV 50 PLUS User Manual

SECTION 11
SPECIFICATIONS
p. 11-1
49836240
SECTION 11 SPECIFICATIONS
11 Specifications
Following are the specifications for the KMT Waterjet SLIV Plus Waterjet Pump.
Included are the specifications for the equipment, torque, cutting water, cooling water,
and the maximum quantity of orifices that can be supported. 30hp and 50hp power
units are listed.
11.1 Equipment Specifications
SL-IV Waterjet Pump Size
22 (30) 37 (50) kW (hp)
Installation location
Indoors Indoors
-Air borne dust/contaminants Minimal Minimal
Ambient temperature
-Minimum storage 2(36) 2(36)
°C(°F)
-Minimum operating 5(40) 5(40)
°C(°F)
-Maximum operating 40(104) 40(104)
°C(°F) (see note [1])
Maximum Relative Humidity (see note [2])
-At Maximum Operating Temp. 95% 95%
Electrical (see note [3])
-Motor type TEFC TEFC (see note [4])
200/3/50 92 150
208/3/60 88 144
240/3/60 80 130
400/3/50 46 75
415/3/50 44 72
480/3/60 40 65
Voltage / Service Amps
575/3/60 32 52
Volts/Phase/Hertz/Amps
Sound Level 72.5 72.5 dB(A) (see note [5])
(Note: Specifications listed below apply equally to 30 hp and 50 hp models)
Controls
-Voltage 24 volts, DC
-Power Supply 10 amps, DC
-Safety shutdown switch settings
High oil temperature 62 (144)
°C (°F)
Low inlet water pressure 2 (30) bar (psi)
Low oil level 80 (21) l (gal).
Booster pump overheat 53 (128)
°C (°F) (see note [5])
Low booster pressure 4 (60) bar (psi)
Hydraulic System
-Oil tank capacity 106 (28) l (gal)
-Recommended oil type
Regular applications
Mobil, DTE Heavy Medium, # 021029
(IR # 05022702)
Food applications Conoco AA-20 (IR # 49835762)
-Hydraulic oil operation
Minimum temperature 15(60) 15(60)
°C(°F)
Maximum temperature 65(150) 65(150)
°C(°F)
