KNS supertrack S3 - Installation of Four Satellites’ TV Receivers with European LNB

16
RF1 RF2 RF3 RF4 ACU
IRD #4IRD #3IRD #2
90~230VAC
50~60Hz
PC
Diagnostics
ANTENNA
Antenna Control Unit
(ACU)
RECEIVER
Vertical
/Low
Horizontal
/Low
Horizontal
/High
Vertical
/High
OUT1 OUT2
OUT3
OUT4
4X4
Multiswitch
*We recommend Aspen’s P7002 splitter.
Power/Data
RF RF RF RF
Passive *
Splitter
DC
Pass
Master IRD
SAT IN TV
Figure 2-15 Installation of Four Satellites’ TV Receivers with European LNB when
auto-switching the satellite using DiSEqC
