Appendix C: Specifications
Above Deck
Antenna Dish Diameter 39 cm Antenna Dimensions 56.5cm(H) x 44.6cm(D)
Antenna Weight 14Kg Radome Material Plastic
Minimum EIRP 48 dBW Azimuth Range 640°
Skew Control
Automatic
(-50° ~ +50° )
LNB Quad / Quattro
Cross Angle +/- 25° Tracking Speed More than 90°/ sec
Platform 3-axis Elevation Angle -10° to +100°
GPS Yes Vibration Damper Rubber Damper
DiSEqC DiSEqC 1.2 Temperature -25°C to +55°C
Humidity Up to 100% @ 40°C
Below Deck
ACU Size 218 x 153 x 50mm External I/O RS232C
Input Power 110/220 VAC Output Power 24VDC 60W
Packing
Size 48 x 48 x 81cm Gross Weight 18kg
Packed by Paper carton
