WiFi Access Point Functional Components Overview
The WiFi access point is the wireless equivalent of the wired internal Local Area Network (LAN). The
WiFi access point provides connectivity between the computer and the RVG sensor(s) enabling you to
use the KODAK RVG 6500 within your practice area. See the manufacturer guide for any detailed
information on the WiFi access point.
Figure 4 WiFi AP Back Panel Overview
Figure 5 WiFi Access Point Front Panel Overview
1 Power adapter outlet.
2 4 local LAN 10/100 Mpbs Ethernet ports for connecting the WiFi AP to the local computers.
3 Wireless antenna.
1 Power indicator
2 Tes t indi c a tor
3 Wireless transmission indicator
4 Local Area Network (LAN) indicator
1
2
3
NETGEAR
1234
1
2 43
