KODAK RVG 6500 System_User & Installation Guide (SM728)_Ed01 35
Preparing the X-Ray Generator
To prepare the x-ray generator, follow these steps:
1 Press the remote control button of the selected RVG control box to access the RVG Acquisition
interface.
(Optional) Press on the remote control button several times to pre-orient the sensor orientation.
The acquired image is displayed with the last selected orientation on the Imaging Window.
(Optional) Click To select the tooth or teeth number. Click to return to the RVG
Acquisition interface. The selected tooth number is displayed on the RVG Acquisition interface.
2 Select the x-ray timing according to the region of interest and the patient type (follow the user
instructions of your x-ray generator).

Kodak RVG 6500 IPS System Specifications

General

Brand	Kodak
Model	RVG 6500 IPS System
Category	Medical Equipment
Language	English
