Kodak RVG 6500 IPS System User Manual

KODAK RVG 6500 System_User & Installation Guide (SM728)_Ed01 33
7 In the RVG Acquisition interface, click to access the RVG sensor list. If needed, click to
refresh the sensor list.
8 Find the selected RVG sensor in the sensor list:
If
do the following:
Click to lock the sensor to your computer, becomes .
If do the following:
Click to unlock from the computer it is locked to and press quickly on the
remote control
button while
the light is blink blue (A). If the unlocking was not executed you must redo the
unlocking process.
Click to lock the sensor to your computer,
becomes .
9 Click to return to the RVG Acquisition interface.
A
B

Kodak RVG 6500 IPS System Specifications

General

Brand	Kodak
Model	RVG 6500 IPS System
Category	Medical Equipment
Language	English
