CVS-128/128B Contents
0093112802-06 vii
Change the bottom color ......... 2-17
Change the image partition ...... 2-17
Display the frequency / Stop the
display of frequency ................. 2-17
Selecting a display area of fish
symbol indication ..................... 2-17
Chapter 3 How to use the menu2 ............ 3-1
3.1 Display of Menu ......................... 3-1
Display the menu ....................... 3-1
Return to the normal menu ........ 3-1
3.2 Setting of External Input/Output . 3-1
Buzzer Setting ............................ 3-1
Temp Source .............................. 3-1
Speed Source ............................ 3-1
Baud Rate .................................. 3-1
NMEA Monitor ............................ 3-2
NMEA Output Data .................... 3-2
3.3 Setting of Correction Item .......... 3-2
Draft Set ..................................... 3-2
Sonic Speed ............................... 3-2
Water Temp ................................ 3-2
Boat Speed ................................ 3-2
Directivity angle (Low/High) ....... 3-2
Bubble ........................................ 3-3
Bubble time set .......................... 3-3
3.4 Setting of Basic Set Item ........... 3-3
Language ................................... 3-3
Range & Speed Unit .................. 3-3
Depth Unit .................................. 3-3
Temperature Unit ....................... 3-3
Local time Offset ........................ 3-3
GPS select ................................. 3-3
GPS initialize .............................. 3-3
3.5 Maintenance Menu .................... 3-3
Simulation .................................. 3-3
Slide show .................................. 3-4
Initialize ...................................... 3-4
System Check ............................ 3-4
All WPTs deletes ........................ 3-4
All stored image deletes ............ 3-4
Bottom start ................................ 3-4
Past image ................................. 3-4
Inner-hull .................................... 3-4
TD select .................................... 3-4
3.6 Setting of Adjust2 Item ............... 3-4
STC strength adjust Low / High . 3-4
STC depth adjust Low / High ..... 3-4
Color adjust ................................ 3-5
Image speed adjust.................... 3-5
Bottom limit ................................ 3-5
Sounding .................................... 3-5
3.7 Frequency select ........................ 3-5
Frequency select (Low / High) ... 3-5
Power frequency adjustment ..... 3-5
Chapter 4 Maintenance and Inspection .. 4-1
4.1 Inspection ................................... 4-1
4.2 Cleaning ..................................... 4-1
CVS-128/128B Display unit ....... 4-1
Transducer ................................. 4-1
4.3 Fuse Replacement ..................... 4-2
4.4 If you suspect a trouble .............. 4-2
4.5 Diagnostic Test ........................... 4-3
Diagnose .................................... 4-3
Confirm the version .................... 4-3
Return to the menu .................... 4-3
Chapter 5 Installation .............................. 5-1
5.1 Items of Caution on Installation . 5-1
Unpacking the components ....... 5-1
Inspection of components and
accessories ................................ 5-1
Decision of Installing Location ... 5-1
Laying and Connection of Cable 5-2
Confirmation after Installation .... 5-2
5.2 Installation of CVS-128/128B
Display unit ................................ 5-3
Desk-top Installation .................. 5-3
