Koden CVS-128 - Connection of External Speaker for Sona-Tone TM; (Prepared by a Customer); Connection of External Monitor (J7) (Prepared by a Customer)

CVS-128/128B Chapter 5 Installation
0093112802-06 5-13
Connection of External Speaker for Sona-Tone
TM
(Prepared by a customer)
The ø3.5 stereo jack is provided to the power cable.
If you connect the speaker with the amplifier to the external, you can clearly hear the Sona-Tone
TM
sound.
Adjust the volume of speaker with the amplifier equipped to the speaker
3.5 stereo jack
Connection of External Monitor (J7) (Prepared by a customer)
When installing an external monitor (VGA monitor, analog RGB input), connect it via CW-576-0.5M. For
its wiring, refer to the illustration below.
Structure of CW-576-0.5M
Nonuse
