Koden CVS-128 - Setting of Key Lock; Change the Scale Type; Change the Bottom Color; Change the Image Partition

CVS-128/128B Chapter 2 How to use the menu
0093112802-06 2-17
or [ ] key)
5 Press the [ ] key.
6 Select the color. (Press the [ ] key or [ ]
key)
7 Press the [MENU] key to close the menu.
Setting of Key lock
Disable the functions of controls and keys to
avoid deviation of these settings by
unintentionally touching them during operation.
1 Press the [MENU] key.
2 Select the [System]  [Key lock]. (See [2.1
How to operate the menu])
3 Press the [ ] key.
4 Select the [Key lock]. (Press the [ ] key or
[
] key)
5 Press the [ ] key.
6 Select the [ON] or [OFF]. (Press the [ ]
key or [
] key)
7 Press the [MENU] key to close the menu.
Change the scale type
The interval of indications of scale can be
changed.
1 Press the [MENU] key.
2 Select the [Display2]  [Scale type]. (See
[2.1 How to operate the menu])
3 Press the [ ] key.
4 Select the [Scale type]. (Press the [ ] key
or [
] key)
5 Press the [MENU] key to close the menu.
Change the bottom color
The dark red color of sea bottom can be
changed.
1 Press the [MENU] key.
2 Select the [Display2]  [Color table 2]
[Bottom color]. (See [2.1 How to operate
the menu])
3 Press the [ ] key.
4 Select the [Bottom color]. (Press the [ ]
key or [
] key)
Black  0, , , 176, , , 255  Red
5 Press the [MENU] key to close the menu.
Change the image partition
The image partition of echo sounder can be
change to "Horizontal split" or “Vertical split”.
1 Press the [MENU] key.
2 Select the [Image]  [Image partition].
(See [2.1 How to operate the menu])
3 Press the [ ] key.
4 Select the [Image partition]. (Press the [ ]
key or [
] key)
5 Press the [MENU] key to close the menu.
Display the frequency / Stop the
display of frequency
The frequeny of the transducer currently in use
can be displayed.
1 Press the [MENU] key.
2 Select the [Display2] → [Freq display].
(See [2.1 How to operate the menu])
3 Press the [ ] key.
4 To display the Freq display, select the [ON].
To stop the display of Freq display, select
the [OFF]. (Press the [
] key or [ ] key)
5 Press the [MENU] key to close the menu.
For CVS-128B
Selecting a display area of fish
symbol indication
The fish symbol can be displayed either on side
A or on side B, or on both sides, by the
following operation.
1 Press the [MENU] key.
2 Select the [Image]  [Fish image]. (See
[2.1 How to operate the menu])
3 Press the [ ] key.
4 Select the [A|B], [A| ], [ |B]. (Press the [ ]
key or [
] key)
5 Press the [MENU] key to close the menu.
