CVS-128/128B Chapter 2 How to use the menu
0093112802-06 2-15
Change the depth value
The display size of depth value can be
changed.
1 Press the [MENU] key.
2 Select the [Display1]  [Depth value].
(See [2.1 How to operate the menu])
3 Press the [ ] key.
4 Select the size of display. (Press the [ ]
key or [
] key)
5 Press the [MENU] key to close the menu.
Display the depth unit / Stop the
display of depth unit
The depth unit can be displayed.
1 Press the [MENU] key.
2 Select the [Display1] → [Unit display]. (See
[2.1 How to operate the menu])
3 Press the [ ] key.
4 To display the depth unit, select the [ON].
To stop the display of depth unit, select the
[OFF]. (Press the [
] key or [ ] key)
5 Press the [MENU] key to close the menu.
Display the water temp graph/Stop
the display of water temp graph
The latest water temp value and the graph of
past water temp data can be displayed.
1 Press the [MENU] key.
2 Select the [Display1]  [Water temp
graph]. (See [2.1 How to operate the
menu])
3 Press the [ ] key.
4 To display the water temp graph, select the
[ON].
To stop the display of water temp graph,
select the [OFF]. (Press the [
] key or [ ]
key)
5 Press the [MENU] key to close the menu.
Setting of the background color of
NAV display
The color of background of navigation display
(NAV1, NAV2) can be changed.
1 Press the [MENU] key.
2 Select the [NAV]  [Background color].
(See [2.1 How to operate the menu].)
3 Press the [ ] key.
4 Select the [Background color]. (Press the
[
] key or [ ] key)
5 Press the [MENU] key to close the menu.
Setting of the echo sounder display
at NAV display
The sounder display can be selected at NAV
(NAV 1, NAV 2) to be displayed.
1 Press the [MENU] key.
2 Select the [NAV]  [NAV1 (2)]. (See [2.1
How to operate the menu])
3 Press the [ ] key.
4 Select the echo sounder display at [NAV 1]
or [NAV 2] to be displayed. (Press the [
]
key or [
]
key)
5 Press the [MENU] key to close the menu.
Image Swap
The images of echo sounder at the right and left
sides can be swapped.
1 Press the [MENU] key.
2 Select the [Image]  [Image swap]. (See
[2.1 How to operate the menu])
3 Press the [ ] key.
4 Select the swap state [A|B],[B|A]. (Press
the [
] key or [ ] key)
5 Press the [MENU] key to close the menu.
Display the Operation guide/Stop the
display of Operation guide
When displaying the menu, it sets whether or
not the operation guide is displayed at the lower
part on the display.
