1 General
1.1 About this manual
This manual describes the wiring, setup, range of functions and software protocol for the
SERVOSTAR 300 (S300), SERVOSTAR 400 (S400), SERVOSTAR 600 ( S600) and S700.
S300
, S600 and S700:
The expansion card -PROFIBUS- offers PROFIBUS compatible connectivity to these servo amplifi
-
ers. The expansion card and it's mounting is described in the instructions manual.
The expansion card for S300 and S700 is different from the card for S600. The text "PROFIBUS
DP" on the front label marks the card for S300/S700, the text "PROFIBUS" the card for S600.
S400
-PROFIBUS:
PROFIBUS functionality is built-in on delivery.
This manual is part of the complete documentation of the digital servo amplifiers. The installation
and setup of the servo amplifier, as well as all the standard functions, are described in the corre
-
sponding instructions manuals.
Other parts of the documentation of the digital servo amplifiers:
Title
Publisher
Instructions manual for the Servo Amplifier Kollmorgen
Online-Help with Object Reference Guide Kollmorgen
Further documentation:
Title
Publisher
Installation Guideline for PROFIBUS DP/FMS PNO
Profile for Variable Speed Drives PNO
SINEC Produktinformation S79200-A0737-X-02-7437 Siemens
SINEC Installationsanleitungen S79200-A0737-X-01-7419 Siemens
SINEC Einführung CP5412 (A2) C79000-G8900-C068 Siemens
SINEC DP-Masterbetrieb mit dem COML DP projektieren C79000-G8900-C069 Siemens
SINEC DP-Programmierschnittstelle C79000-G8900-C071 Siemens
1.2 Target group
This manual addresses personnel with the following qualifications:
Transport : only by personnel with knowledge of handling electrostatically sensitive
components.
Unpacking: only by electrically qualified personnel.
Installation : only by electrically qualified personnel.
Setup : only by qualified personnel with extensive knowledge of electrical
engineering and drive technology
Programming: Software developers, project-planners, experienced PLC programmers
with PROFIBUS DP expertise
The qualified personnel must know and observe the following standards:
IEC 60364, IEC 60664, and regional accident prevention regulations.
Qualified Personnel only!
During operation there are deadly hazards, with the possibility of death,
severe injury or material damage.
l
The user must ensure that the safety instructions in this manual are
followed.
l
The user must ensure that all personnel responsible for working with
the servo amplifier have read and understood the instructions manual.
Training courses are available on request.
PROFIBUS for S300/S400/S600/S700 5
Kollmorgen 04/2017 General
