6 Technical description
6.1 The SERVOSTAR 600 family of digital servo amplifiers
Standard version
l
6 current ratings (1.5 A -Europe only-,3A,6A,10A,14A,20A)
l
3 instrument widths : 70 mm for 1.5A up to 10A rated current
100 mm for 14A rated current
120 mm for 20A rated current
l
Wide range of rated voltage (3x208V
–10%
to 3x480V
+10%
)
l
Overvoltage category III acc. to EN 61800-5-1
l
Shield connection directly at the servo amplifier
l
2 analog setpoint inputs
l
Integrated CANopen (default 500 kBaud), for integration into CAN bus systems and for
setting parameters for several amplifiers via the PC-interface of one amplifier
l
Integrated RS232, electrically isolated, integrated pulse-direction interface
l
Synchronous servomotors, linear motors and asynchronous motors can be used
Electrical supply
l
Directly off grounded 3 phase system,
230V
-10%
... 480V
+10%
,50Hz,
208V
-10%
... 480V
+10%
,60Hz
TN-system or TT-system with grounded neutral point, max. 42,000 rms symmetrical amperes.
Connection to other mains supply networks only with insulating transformer ð p.48
l
B6 rectifier bridge, directly off 3-phase earthed (grounded) supply system, integral power input
filter and inrush circuit
l
Single-phase supply (e.g. for setup) is possible
l
Fusing: (e.g. fusible cutout) provided by the user
l
Shielding: All shielding connections directly on the amplifier
l
Output stage: IGBT- module with isolated current measurement
l
Brake circuit: with dynamic distribution of the brake power between several
amplifiers on the same DC bus link circuit. Internal brake resistor as
standard, external brake resistors if required
l
DC bus link voltage 260 — 900 VDC, can be switched in parallel
l
Interference suppression filter for the supply input (to category 3) is integrated
l
Interference suppression filter for the 24V aux. supply (to category 3) is integrated
Integrated safety
l
Safe electrical separation between the power input / motor connections and the signal electro
-
nics, provided by appropriate insulation/creepage distances and complete electrical isolation
l
Soft-start, overvoltage recognition, short-circuit protection, phase-failure monitoring
l
Temperature monitoring of servo amplifier and motor
(when using our motors with our pre-assembled cables)
SERVOSTAR
®
601...620 Instructions Manual 21
Kollmorgen
07/2010 Technical description
