9.3.1.3 Minimum Wiring for Drive Test
This wiring does not fulfill any requirements to safety or functionality of your application, it
just shows the required wiring for drive testing without load.
SERVOSTAR
®
601...620 Instructions Manual 75
Kollmorgen
07/2010 Setup
Power ON
24V DC
+
-
Enable
Power
Motor-Feedback
Motor-Power
Motor
2
3
15
1
2
3
X4
X3
24V ON
18
RES
ENC
PC
CAN
