6.2.4 Conductor cross-sections
Technical data for connection cables ð p.42. Following EN 60204 (for AWG: table 310-16 of the
NEC 60°C or 75°C column), we recommend for single-axis systems:
AC connection
SERVOSTAR 601-610: 1.5 mm² (14awg)
SERVOSTAR 614/620: 4 mm² (12awg)
600V,80°C (176°F),
twisted
DC bus link
SERVOSTAR 601-610: 1.5 mm² (14awg)
SERVOSTAR 614/620: 4 mm² (12awg)
600V,80°C (176°F),
shielded for
lengths>20cm
Motor cables
up to 25 m length*
SERVOSTAR 601-610: 1-1.5 mm² (14awg)
SERVOSTAR 614/620: 2.5 mm² (12awg)
600V,80°C (176°F),
shielded,
capacitance <150pF/m
Motor cables
25 to 100 m length*,
with motor choke 3YL
SERVOSTAR 601-606: 1 mm² (14awg)
SERVOSTAR 610-620: 2.5 mm² (12awg)
600V,80°C (176°F),
shielded,
capacitance <150pF/m
Resolver, thermal control,
max.100m length*
4x2x0.25 mm² (22awg) twisted pairs, shielded,
capacitance <120pF/m
Encoder, thermal control,
max.50m length*
7x2x0,25 mm² (22 awg) twisted pairs, shielded,
capacitance <120pF/m
Setpoints, monitors, AGND 0.25 mm² (22awg) twisted pairs, shielded
Control signals, BTB,
DGND
0.5 mm² (20awg)
Holding brake (motor)
min. 0.75 mm² (18awg), 600V,80°C (176°F), shielded,
check voltage drop
+24 V / XGND max. 2.5 mm² (12awg), check voltage drop
For multi-axis systems, please note the special operating conditions in your installation.
To reach the max. permitted cable length, observe cable requirements ð p. 42.
* Kollmorgen North America delivers cables up to 39m length.
* Kollmorgen Europe delivers cables up to the maximum length.
6.3 LED display
A 3-character LED display shows the amplifier status after switching on the 24V supply (ð p.86).
During operation of the amplifier via the keys on the front panel, the parameter and function num
-
bers (ð p.87) are displayed, as well as the numbers of any errors which occur (ð p.88).
SERVOSTAR
®
601...620 Instructions Manual 25
Kollmorgen
07/2010 Technical description
