5.9.2 External 24V DC / 20A supply
SERVOSTAR
®
601...620 Installation Manual 87
Kollmorgen 03/04 Extensions / Accessories
Technical data
Input voltage 3 x 400VAC ± 10%
Input current ca. 1,1A
Frequency 50/60Hz
Primary fuse none
Output voltage 24V ± 1%
Max. output current 20A
Residual ripple <0,1%
Output fuse short circuit proof
Test voltage acc. to VDE 0550
Temperature range -20...+60°C (-4...140°F)
Type of mounting
on the supplied mounting plate
Keep the required space clear
Weight 3,5kg
