Vers. 062721 19
(2) Reverse button
Press and hold the button to initiate a defix run, rotating in the opposite direction of the
selected direction of rotation for the lever (see Programs menu > Other > ROTATION ).
The behavior of the reverse button can be changed from the general settings menu
(General Settings > REVERSE BUTTON).
(3) LEDs
The two LEDs indicate the state of the screwdriver:
Blinking white: the screwdriver was just connected to the K-DUCER control unit
Off: the screwdriver is ready, or the screwdriver is not connected
Solid green: the last screw result was OK
Solid red: the last screw result was NOK
Solid blue: screwdriver is running in the tightening direction, either via the lever or
via remote control
Solid purple: the screwdriver is running in the de-fix direction, either via the
reverse button, or via remote control
Blinking purple: the reverse button is in switch mode and is activated. The
screwdriver is ready to run in de-fix rotation via the main lever.
(4) Reaction arm connections
Fix the reaction arm to one these areas only, and never anywhere else on the
screwdriver.
Note: KDS series screwdrivers sizes 20Nm and above only provide the lower reaction
arm connection area.
(5) Hanging hook
To hang the screwdriver somewhere easily accessible in the operator’s workbench.
(6) Female connector
To connect the screwdriver to the K-DUCER control unit
