Vers. 062721 76
OPEN PROTOCOL
Introduction
The K-DUCER control unit supports a subset of the Open Protocol communication
interface, based on the Open Protocol specification release 1.6, revision 3.
The Open Protocol communication interface gives the K-DUCER plug-and-play
compatibility with any MES software (Manufacturing Execution System) that supports
Open Protocol 1.6 rev3.
Enable Open Protocol via the General Settings menu > COMMUNICATION PROTOCOL,
selecting “OP”. OP works on TCP/IP port 4545, one connection at a time.
Terminology
Program (numbered 1 through 64)
Number of screws (configured for each program, default 1, max 99)
Sequence of up to 16 programs. Sequences are identified as letters
in the KDucer unit, but as numbers (Job IDs) within the context of
Open Protocol. A=1, B=2, C=3, D=4, E=5, F=6, G=7, H=8
Barcode (for barcode mode “on S/N” only)
Communication Start Acknowledge
Pset selected acknowledge
Pset selected unsubscribe
