OPERATION
MACHINE OPERATIONS AND CONTROLS
MACHINE OPERATION
WARNING
Before operating the travel lever or travel pedal, check the direction that the track frame is facing.
When the track frame is facing the rear (when the sprocket is at the front), the direction of operation of the travel lever and travel
pedal is the opposite to the direction of movement of the machine (forward/reverse, left/right).
Before starting the machine off, check that the area around the machine is safe, and sound the horn.
Do not allow anyone to enter the area around the machine.
Remove any obstacles from the travel path.
The area at the rear of the machine is a blind spot. Always use the rear view camera to check the area at the rear of the machine
before traveling in reverse.
When the auto-deceleration is being used, if the travel lever or travel pedal are operated, the engine speed will suddenly rise,
so be careful when operating the travel lever or travel pedal.
When traveling, check that the travel alarm works properly.
Preparations for Moving the Machine
1.
Set swing lock switch (1) to the ON (actuated) position and
confirm that swing lock monitor lamp (2) lights up.
(a): ON position
(b): OFF position
2.
Turn fuel control dial (3) towards the full speed (MAX) position
to increase the engine speed.
3 - 150
