MAINTENANCE
MAINTENANCE PROCEDURE
CHECK ROAD LINERS
(Machine equipped with road liner)
If the road liners are in the following condition, they must be repaired or replaced, so please contact your Komatsu
distributor for repairs or replacement.
Lug Height
If lug height "a" is reduced by wear, the drawbar pull will drop.
If "a" is less than 5 mm (0.2 in), replace with a new part.
When making judgement whether to replace, repair, or contiune
using road liner, please contact your Komatsu distributor.
REPLACE ROAD LINERS
(Machine equipped with road liner)
When replacing all the road liner for the machine, please contact your Komatsu distributor to have the
replacement carried out.
When replacing only part of the road liner, use the special road liner removal tool. Please order the tool from your
Komatsu distributor.
4 - 28
