OPERATION
TRANSPORTATION
OPERATION
TRANSPORTATION
10. When the machine travels over the rear wheels of the trailer, it
becomes unstable, drive slowly and carefully. (Never operate
the steering.)
11. At the moment the machine passes the rear wheels, it tilts
forward, be careful not to let the work equipment hit the trailer
body. Drive the machine forward to the specified position, then
stop the machine.
12.
Lower the work equipment on top of wooden blocks.
Securing Machine
After placing the machine on the specified position of the trailer, secure it according to the following procedure.
NOTICE
Stow the radio antenna. Reassemble the mirrors so that they are within the width of the machine.
To prevent damage to the bucket cylinder during transportation, put a wooden block under the tip of the bucket link to prevent
the bucket cylinder from touching the floor.
Load the machine onto a trailer as follows:
1.
Lower the blade. (Only machines with blade specification)
2.
Extend the bucket and arm cylinders fully, then lower the boom
slowly.
3.
Set the lock lever securely to the LOCK position (L).
4.
Stop the engine, then remove the key from the starting switch.
5. Close all doors, windows, and covers.
Lock the covers, caps, and doors fitted with locks.
3 - 182
