Komatsu PC138US - Specifications

.
SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
PC138US-8
Item Unit Standard specification Blade specification
Machine weight kg (lb) 13,400 (29,547) 14,050 (30,980)
Bucket capacity m
3
(cu.yd) 0.50 (0.65)
Name of engine - Komatsu SAA4D95LE-5 diesel engine
Engine horsepower kW (HP)/rpm 68.4 (91.7)/2,200
A Overall length (Standard specification) mm (ft in) 7,260 (23' 10") -
A' Overall length (Blade specification) mm (ft in) - 7,970 (26' 2")
B Overall height mm (ft in) 2,850 (9' 4")
C Overall width mm (ft in) 2,490 (8' 2")
D Track width mm (ft in) 500 (1' 8")
E Tail swing radius mm (ft in) 1,480 (4' 10")
F Length of track mm (ft in) 3,610 (11' 10")
G Tumbler canter distance mm (ft in) 2,880 (9' 5")
H Cab height mm (ft in) 2,815 (9' 3")
Min. ground clearance mm (ft in) 395 (1' 4")
Travel speed (Low/High) km/h (MPH) 2.9/5.1 (1.8/3.2)
Continuous swing speed rpm 11.0
5 - 2
