SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
Working ranges Unit PC138US-8 PC138USLC-8
A Max. digging reach mm (ft in) 8,300 (27' 3")
B Max. digging depth mm (ft in) 5,480 (17' 2")
C Max. digging height mm (ft in) 9,340 (30' 8")
D Max. vertical wall digging depth mm (ft in) 4,900 (16' 1")
E Max. dumping height mm (ft in) 6,840 (22' 5")
F Min. swing radius of work equipment mm (ft in) 1,980 (6' 6")
G Max. reach ground level mm (ft in) 8,180 (26' 10")
H Max. blade lifting height mm (ft in) 470 (1' 7")
I Max. blade lowering depth mm (ft in) 525 (1' 9") 490 (1' 7")
5 - 4
