322217/G

TDR30V

Thetransducerhasa30°verticalbeamwidth.

TDR30H

Thetransducerhasa30°horizontalbeamwidth.

Splitforremotetransducer

Thesplitistheconnectionbetweenthetransponderandtheremote

transducer.

Transducercable

Thecableconnectsthetransponderandtheremotetransducer.

KongsbergcNODEInstructionManual
