322217/G

Sensorinterface,PressureandInclination

connectorpinout

Thisisthepincongurationforamaleplug,asseentowardstheplug(faceview).

PinnumberSignal

1RS-422Tx+

2RS-422Tx–

3RS-422Rx+

4RS-422Rx–

RS-232TxSensorinterface

RS-232RxSensorinterface

Ground

Notconnected

13VDCOut

Ground

RS-232TxConguration

RS-232RxConguration

MotionGyroCompassconnectorpinout

Thisisthepincongurationforamaleplug,asseentowardstheplug(faceview).

Cablelayoutandinterconnections
