322217/G

Externalsignalconnectorpinout

Thisisthepincongurationforamaleplug,asseentowardstheplug(faceview).

Pin1,2and3isforconguration.

Pin4and5isforresponderfunction.

PinnumberSignal

RS-232TxConguration

Ground

RS-232RxConguration

Respondertrigger+

Respondertrigger-

On/Off

Notconnected

Ground

KongsbergcNODEInstructionManual
