322217/G
23
Sensorinterfaceconnectorpinout
Thisisthepincongurationforamaleplug,asseentowardstheplug(faceview).
PinnumberSignal
1
RS-232TxSensorinterface1
2
RS-232RxSensorinterface1
3
Ground
4
RS-232TxSensorinterface3
5
RS-232RxSensorinterface3
6
Ground
7
RS-422Tx+/RS-485Data+
8
RS-422Tx–/RS-485Data–
9RS-422Rx+
10RS-422Rx–
11
Ground
12VDCOut1
13VDCOut2
14
Ground
15
On/OffExternal
16
On/OffGround
Cablelayoutandinterconnections
