322217/G

Modulartopsection(MTS)

Severalmodulesareavailablefordifferentversionsofthetopsections.

Soundvelocity,PressureandInclinometer

TheSvPImoduleprovidesafullsuiteofprecisionsurveygrade

sensorsforsubseapositioning.

Itisavailableinaluminiumfordifferentdepthsandaccuracies.

Modem

Themodemletsyousenddataacousticallytoandfromsensorsand

otherequipment.

Thesectionisavailableinaluminium.

Modularendcaps(MEC)

Severalendcapsareavailablefordifferentneeds.

Basicendcap

Thebasicendcaphasaventscrew,safetyvalve,astandardexternal

connectorandisavailableinaluminiumandstainlesssteel.

Releaseendcap

Thereleasemechanismcanalsobettedonabasicendcap.It

isavailableinaluminiumandstainlesssteel.

Systemunits
