Addingweighttothereleaseunit

Thisishowtheanchorweightcanbeattachedtothetransponderbeforeoperation.

Steelshackle

UseastainlesssteelD-shackletoconnecttherope,softorwebliftingslingtothe

releasemechanism.

Note

MaximummaterialthicknessusedintheD-shackleis15mm.

Usingrope,softorwebliftingslingdirectlytothereleasemechanismmightjamthe

releasehook,andthetranspondercouldfailtorelease/open.

Alwaysuseacabletieorsafetywiretosecurethepinattheshackle.

A10mm

B17mm

C16mm

D10mm

Itisrecommendedtouseaminimumof2

mofrope,softorwebliftingslingbetween

theD-shackleattachedtothereleaseunit

andtheweighttoavoidcorrosion.

Anotheroptionistouseaminimumof1

mofrope,softorwebliftingslingbetween

theD-shackleattachedtothereleaseunit

andaminimumof1mofwireorchain

attachedtotheweight.
