322217/G

Maintenancekit

•Partname:cNODEMaxiandMidimaintenancekit,Aluminium

•Partnumber:345595

Thiskitcontains:

•1EMIshield

•1O-ring,12x2mm

•3Zinkanodes207–5000

•3lockingcords

•1UVplug,dummy

•6O-rings,107x5mm

•1O-rings,10x2mm

•1V entscrew

•1Lockingsleeve

•1Transportplug

•6Serratedlockwashers

TD180Sparepart

•Partname:TD180Aluminium

•Partnumber:319750

•Partname:TD180Steel

•Partnumber:320877

TD30V30HSparepart

•Partname:TD30V30HAluminium

•Partnumber:313455

•Partname:TD30V30HSteel

•Partnumber:359429
