322217/G

InclinometersensorSparepart

•InclinometersensorSparepart

•441115

InclinometersensorInterfacecableSpare

part

•Partname:InclinometersensorInterfacecable

Partnumber:322407

AdapterforoatingcollarSparepart

Adapterfortranspondermodelswithoutareleasemechanism.Foruseonabasicend

capwithaoatingcollar.

•Partname:AdapterforoatingcollarAluminium

•Partnumber:369045

•Partname:AdapterforoatingcollarSteel

•Partnumber:372953

FloatingcollarSparepart

•Partname:FloatingcollarAluminium4000m

•Partnumber:319301

•Partname:FloatingcollarAluminium2000m

•Partnumber:320772

•Partname:FloatingcollarSteel4000m

•Partnumber:331151

Spareparts
