Machine Maintenance
13
bizhub 500/420
13-9
Cleaning the control panel
Clean the control panel by wiping it wit
h a
soft, dry cloth.
2
Reminder
Pressing too hard on
the control panel
or the touch panel may dama
ge them.
Never use
a mild
househol
d deterge
nt,
glass cleaner, benzin or thinner to
clean the con
trol panel or touch panel.
