KTD-00782-H KTQ45 family Page 13 of 92
Winbond W83627DHG LPC Bus I/O Controller
• Eight USB 2.0 ports on I/O area
• Four USB 2.0 ports on internal pinrows
• Two Serial ports (RS232) KTQ45/Flex, Four Serials ports 3x(RS323), 1x(RS485)
(Galvanic isolated) with full duplex support on KTQ45/ATXE
• One Parallel port, SPP/EPP/ECP
• Five Serial ATA-300 IDE interfaces with RAID 0/1/5/10 support
• PS/2 keyboard and mouse ports
• 1x 10/100/1000Mbits/s using NIC Intel® Boazman-LM WG82567LM (ETHER1)
(connected to ICH10DO Integrated GbE MAC supporting AMT 5.0)
• 1x 10/100/1000Mbits/s using NIC Intel® Hartwell 82574L (ETHER2)
• PXE netboot supported. Wake On LAN (WOL) supported.
• Kontron Technology / AMI BIOS (core version)
• Support for Advanced Configuration and Power Interface (ACPI 3.0), Plug and Play
o Suspend To Ram
o Suspend To Disk
o Intel Speed Step
• Secure CMOS/ OEM Setup Defaults
• “Always On” BIOS power setting
• RAID Support (RAID modes 0, 1, 5 and 10) (for Linux O/S only RAID 0 and 1)
• PCI Bus routed to PCI slot(s) (PCI Local Bus Specification Revision 2.3)
o KTQ45/Flex: 2 slots PCI 2.3, 32 bits, 33 MHz, 5V compliant
o KTQ45/ATXE: 4 slots PCI 2.3, 32 bits, 33 MHz, 5V compliant
• PCI-Express bus routed to PCI Express slot(s) (PCI Express 2.0)
o KTQ45/Flex and KTQ45/ATXE:
1 slot PCI-Express x16 (PCI Express 2.0)
1 slot PCI-Express x4 (PCI Express 1.1)
• SMBus routed to FEATURE, PCI slot, PCI Express
• LPC Bus routed to TPM connector
• DDC Bus routed to CRT connector
• 8 x GPIOs (General Purpose I/Os) routed to FEATURE connector
• Smart Fan control system, support Thermal® and Speed® cruise for three onboard
Fan control connectors: FAN_CPU, FAN_SYS and FEATURE
•
Three thermal inputs: CPU die temperature, System temperature and External
temperature input routed to FEATURE connector. (Precision +/- 3ºC)
• Voltage monitoring
• Intrusion detect input
•
SMI violations (BIOS) on HW monitor not supported. Supported by API (Windows).
• Linux: Red Hat 5 U2, SuSe 10 SP2 (limitations may apply)
