4 Onboard connectors and Mating connectors
Connector
Onboard Connectors
Mating Connectors
Manufacturer
Type no.
Manufacturer
Type no.
FAN_CPU
Foxconn
HF2704E-M1
AMP
1375820-4 (4-pole)
FAN_SYS
AMP
1470947-1
AMP
1375820-3 (3-pole)
KBDMSE
Molex
22-23-2061
Molex
22-01-2065
CDROM
Foxconn
HF1104E
Molex
50-57-9404
Molex
70543-0038
SATA
Hon Hai
LD1807V-S52T
Molex
67489-8005
Kontron
KT 821035 (cable kit)
ATXPWR
Molex
43045-1201
Molex
43025-1200
ATX+12V-4pin
Molex
22-23-2041
Molex
22-01-2046
ATX+12V-6pin
Molex
22-23-2041
Molex
22-01-2046
COM2, 3, 4
Wuerth
61201020621
Molex
90635-1103
Kontron
KT 821016 (cable kit)
Kontron
KT 821017 (cable kit)
USB8/9
Pinrex
512-90-10GBB2
Kontron
KT 821401 (cable kit)
USB10/11*
(FRONTPNL)
-
Kontron
KT 821401 (cable kit)
PRINTER
Foxconn
HL2213F
Molex
90635-1263
Kontron
KT 821031 (cable kit)
AUDIO_HEAD
Molex
87831-2620
Molex
51110-2651
Kontron
KT 821043 (cable kit)
FRONTPNL
Pinrex
512-90-24GBB3
Molex
90635-1243
Kontron
KT 821042 (cable kit)
FEATURE
Molex
87831-3020
Molex
51110-3051
Kontron
KT 821041 (cable kit)
* USB10/USB11 is located in FRONTPNL connector. Depending on application the KT821401 can be used.
Note: Only one connector will be mentioned for each type of onboard connector even though several types
with same fit, form and function are approved and could be used as alternative. Please also notice that
standard connectors like DVI, PCIe, PCI, CF, Ethernet and USB are not included in the list.
