3.4 Display connector
The KTQ45 board family provides onboard Analogue CRT interface. Additionally the KTQ45 boards provides
support for ADD2 cards through the onboard PCI Express x16 connector, with extension capability for
support of DVI, LVDS, VGA, HDMI/UDI, TV-Out, etc.
If a PCI Express x16 Graphics add-in card is used, the onboard Graphics controller (GMA 4500) is disabled.
3.4.1 CRT Connector (CRT)
Note
Pull
U/D
Ioh/Iol Type Signal PIN Signal Type Ioh/Iol
Pull
U/D
Note
6
GND
PWR
-
-
/75R
*
A0
RED
1
11
NC
-
-
-
7
GND
PWR
-
-
/75R
*
A0
GREEN
2
12
DDCDAT
IO
TBD
2K2
8
GND
PWR
-
-
/75R
*
A0
BLUE
3
13
HSYNC
O
TBD
9
5V
PWR
-
-
1
-
-
-
NC
4
14
VSYNC
O
TBD
10
GND
PWR
-
-
-
-
PWR
GND
5
15
DDCCLK
IO
TBD
2K2
Signal Description - CRT Connector:
Pin Signal Description
1
RED
Analogue output carrying the red colour signal to the CRT. For 75 Ohm cable impedance.
2
GREEN
Analogue output carrying the green colour signal to the CRT. For 75 Ohm cable impedance.
3
BLUE
Analogue output carrying the blue colour signal to the CRT. For 75 Ohm cable impedance.
4
NC
No Connection
5-8
GND
9
5V
This 5V supply is fused by a 1.1A resettable fuse.
10
GND
11
NC
No Connection
12
DDCDAT
Display Data Channel Data. Used as data signal to/from monitors with DDC interface.
13
HSYNC
CRT horizontal synchronization output.
14
VSYNC
CRT vertical synchronization output.
15
DDCCLK
Display Data Channel Clock. Used as clock signal to/from monitors with DDC interface.
