6.10.3 Advanced Chipset Settings – South Bridge Chipset Configuration
BIOS SETUP UTILITY
Chipset
South Bridge Chipset Configuration
Disabled
2 USB Ports
4 USB Ports
6 USB Ports
8 USB Ports
10 USB Ports
12 USB Ports
<-> Select Screen
|| Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
USB Functions [8 USB Ports]
USB Port Configure [6x6 USB Ports]
USB 2.0 Controller [Enabled]
HDA Controller [Enabled]
Audio Jack Sensing [Auto]
SMBUS Controller [Enabled]
Restore on AC Power Loss [Power on]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
Feature
Options
Description
USB Functions
Disabled
2 USB Ports
4 USB Ports
6 USB Ports
8 USB Ports
10 USB Ports
12 USB Ports
Disabled
2 USB Ports
4 USB Ports
6 USB Ports
8 USB Ports
10 USB Ports
12 USB Ports
USB Port Configure
6x6 USB Ports
8x4 USB Ports
6x6 USB Ports
8x4 USB Ports
USB 2.0 Controller
Disabled
Enabled
If above function “USB Function” = 10 or 12 USB
Ports then USB 2.0 Controller is always enabled
HDA Controller
Disabled
Enabled
Disabled
Enabled
Audio Jack Sensing
Auto
Disabled
Auto: The insertion of audio jacks is auto
determined.
Disabled: Driver assumes that all jacks are inserted
(useful when using Audio pinrow)
SMBUS Controller
Enabled
Disabled
Disabled
Enabled
Restore on AC Power Loss
Power Off
Power On
Last State
Power Off
Power On
Last State
