Kontron KTQ45/Flex - USB Connector 8;9 (USB8;9); USB Connector 10;11 (USB10;11)

KTD-00782-H KTQ45 family Page 40 of 92
3.10.4 USB Connector 8/9 (USB8/9)
USB Ports 8 and 9 are supplied on the internal USBC1 pinrow connector.
Note
Pull
U/D
Ioh/Iol Type
Signal PIN Signal Type Ioh/Iol
Pull
U/D
Note
1
-
PWR
5V/SB5V
1
2
5V/SB5V
PWR
-
1
-
IO
USB8-
3
4
USB9-
IO
-
-
IO
USB8+
5
6
USB9+
IO
-
-
PWR
GND
7
8
GND
PWR
-
-
-
KEY
9
10
NC
-
-
Note 1: In order to meet the requirements of USB standard, the 5V input supply must be at least 5.00V.
Signal
Description
USB8+ USB8-
USB9+ USB9-
Differential pair works as Data/Address/Command Bus.
5V/SB5V 5V supply for external devices. SB5V is supplied during powerdown to allow wakeup on
USB device activity. Protected by resettable 1.1A fuse covering both USB ports.
3.10.5 USB Connector 10/11 (USB10/11)
See Frontpanel Connector (FRONTPNL) description.
