3.3 Keyboard and Mouse connectors
Attachment of a keyboard or PS/2 mouse adapter can be done through the stacked PS/2 mouse and
keyboard connector (MSE & KBD).
Both interfaces utilize open-drain signalling with on-board pull-up.
The PS/2 mouse and keyboard is supplied from SB5V when in standby mode in order to enable keyboard or
mouse activity to bring the system out from power saving states. The supply is provided through a 1.1A
resettable fuse.
3.3.1 MINI-DIN Keyboard and Mouse Connector (KBD)
Note
Pull
U/D
Ioh/Iol Type Signal PIN Signal Type Ioh/Iol
Pull
U/D
Note
-
-
-
NC
6
5
MSCLK
IOC
TBD
2K7
-
-
PWR
5V/SB5V
4
3
GND
PWR
-
-
-
-
-
NC
2
1
MSDAT
IOC
TBD
2K7
-
-
-
NC
6
5
KBDCLK
IOC
TBD
2K7
-
-
PWR
5V/SB5V
4
3
GND
PWR
-
-
-
-
-
NC
2
1
KBDDAT
IOC
TBD
2K7
Signal Description – Keyboard & and mouse Connector (MSE & KBD), see below.
3.3.2 Keyboard and Mouse pinrow Connector (KBDMSE)
PIN Signal Type Ioh/Iol
Pull
U/D
Note
1
KBDCLK
IOC
TBD
2K7
2
KBDDAT
IOC
TBD
2K7
3
MSCLK
IOC
TBD
2K7
4
MSDAT
IOC
TBD
2K7
5
5V/SB5V
PWR
-
-
6
GND
PWR
-
-
Signal Description – Keyboard & and mouse Connector (KBDMSE).
Signal Description
MSCLK Bi-directional clock signal used to strobe data/commands from/to the PS/2 mouse.
MSDAT Bi-directional serial data line used to transfer data from or commands to the PS/2 mouse.
KDBCLK Bi-directional clock signal used to strobe data/commands from/to the PC-AT keyboard.
KBDDAT Bi-directional serial data line used to transfer data from or commands to the PC-AT keyboard.
