Kontron KTQ45/Flex - Audio Header (AUDIO_HEAD)

KTD-00782-H KTQ45 family Page 43 of 92
3.11.3 Audio Header (AUDIO_HEAD)
Note
Pull
U/D
Ioh/
Iol
Type Signal PIN Signal Type
Ioh/
Iol
Pull
U/D
Note
LFE-OUT
1
2
CEN-OUT
AAGND
3
4
AAGND
FRONT-OUT-L
5
6
FRONT-OUT-R
AAGND
7
8
AAGND
REAR-OUT-L
9
10
REAR-OUT-R
SIDE-OUT-L
11
12
SIDE-OUT-R
AAGND
13
14
AAGND
MIC1-L
15
16
MIC1-R
AAGND
17
18
AAGND
LINE1-IN-L
19
20
LINE1-IN-R
NC
21
22
AAGND
-
-
PWR
GND
23
24
SPDIF-IN
SPDIF-OUT
25
26
GND
PWR
-
-
Signal Description Note
FRONT-OUT-L Front Speakers (Speaker Out Left).
FRONT-OUT-R Front Speakers (Speaker Out Right).
REAR-OUT-L Rear Speakers (Surround Out Left).
REAR-OUT-R
Rear Speakers (Surround Out Right).
SIDE-OUT-L Side speakers (Surround Out Left)
SIDE-OUT-R Side speakers (Surround Out Right)
CEN-OUT Center Speaker (Center Out channel).
LFE-OUT
Subwoofer Speaker (Low Freq. Effect Out).
NC No connection
MIC1 MIC Input 1
LINE1-IN Line in 1 signals
F-SPDIF-IN S/PDIF Input
F-SPDIF-OUT S/PDIF Output
AAGND Audio Analogue ground
