Kontron KTQ45/Flex - KTQ45;ATXE Connector Layout

KTD-00782-H KTQ45 family Page 26 of 92
PCI Slot3
PCI Slot4
PCIe x4
Ext-TPM
FAN_SYS
COM4*
COM3*
J9, J8, J7*
LPT
Connectors are at the same location as on KTQ45/Flex,
except for the pointed out connectors. The connectors with
an “*” indicates only available on KTQ45/ATXE.
3.1.3 KTQ45/ATXE
