5 System Resources
5.1 Memory Map
Address (hex)
Size
Description
00000000
0009FFFF
655360
System board
000A0000
000BFFFF
131072
PCI-bus
000A0000
000BFFFF
131072
Intel(R) Q45/Q43 Express Chipset
000C0000
000CFFFF
65536
System board
000D0000
000DFFFF
65536
PCI-bus
000E0000
000FFFFF
131072
System board
00100000
CDDFFFFF
3452960768
System board
CDE00000
DFFFFFFF
304087040
PCI-bus
D0000000
DFFFFFFF
268435456
Intel(R) Q45/Q43 Express Chipset
E0000000
EFFFFFFF
268435456
Motherboard resources
F0000000
FED8FFFF
249102336
PCI-bus
FE400000
FE7FFFFF
4194304
Intel(R) Q45/Q43 Express Chipset
FEAC0000
FEADFFFF
131072
Intel(R) 82567LM-3 Gigabit Network Connection
FEAF0000
FEAF3FFF
16384
Microsoft UAA-bus driver for High Definition Audio
FEAF4000
FEAF43FF
1024
Intel(R) ICH10 Family USB Enhanced Host Controller - 3A6A
FEAF6000
FEAF63FF
1024
Intel(R) ICH10 Family USB Enhanced Host Controller - 3A6C
FEAF8000
FEAF8FFF
4096
Intel(R) 82567LM-3 Gigabit Network Connection
FEAFB800
FEAFB8FF
256
Intel(R) ICH10 Family SMBus Controller - 3A60
FEAFBC00
FEAFBC0F
16
Intel(R) Management Engine Interface
FEB00000
FEBFFFFF
1048576
Intel(R) ICH10 Family PCI Express Root Port 5 - 3A78
FEBDC000
FEBDFFFF
16384
Intel(R) 82574L Gigabit Network Connection
FEBE0000
FEBFFFFF
131072
Intel(R) 82574L Gigabit Network Connection
FEC00000
FEC00FFF
4096
Motherboard resources
FED14000
FED19FFF
24576
System board
FED1C000
FED1FFFF
16384
Motherboard resources
FED20000
FED3FFFF
131072
Motherboard resources
FED40000
FED8FFFF
327680
Motherboard resources
FED90000
FED93FFF
16384
System board
FED90000
FFFFFFFF
19333120
System board
FEE00000
FEE00FFF
4096
Motherboard resources
FFB00000
FFBFFFFF
1048576
Intel(R) 82802 Firmware-hub unit
FFC00000
FFEFFFFF
3145728
Motherboard resources
FFF00000
FFFFFFFF
1048576
Intel(R) 82802 Firmware-hub unit
